A Guide to Cable Glands for Flat Cables (Festoon, Pendant)

Introduction

“Samuel, we’ve tried three different cable gland suppliers, and none of them work with our flat festoon cables!” That was the frustrated call I received from Thomas, a crane manufacturer in Hamburg, Germany. His team had been struggling for weeks with standard round cable glands that crushed their flat cables, causing conductor damage and repeated failures. The problem? They were using the wrong cable gland design entirely.

Flat cables used in festoon systems, pendant applications, and traveling crane installations require specialized cable glands designed specifically for non-circular cable profiles, featuring wide-entry designs, adjustable clamping mechanisms, and strain relief systems¹ that distribute pressure evenly across the flat cable surface without deforming the cable geometry. Standard round cable glands will damage flat cables, compromise IP ratings, and create safety hazards in dynamic applications.

Over the past decade, I’ve helped dozens of material handling companies, overhead crane manufacturers, and automated warehouse operators solve their flat cable connection challenges. The key is understanding that flat cables behave completely differently than round cables—and your cable gland selection must reflect that. In this comprehensive guide, I’ll walk you through everything you need to know about selecting, installing, and maintaining cable glands for flat cable applications. 😊

Table of Contents

• What Are Flat Cables and Where Are They Used?
• Why Do Standard Cable Glands Fail on Flat Cables?
• What Types of Cable Glands Work for Flat Cables?
• How Do You Select the Right Flat Cable Gland?
• What Are the Installation Best Practices for Flat Cable Glands?
• FAQs About Cable Glands for Flat Cables

What Are Flat Cables and Where Are They Used?

Flat cables—also called festoon cables, pendant cables, or ribbon cables—have a distinctive rectangular or oval cross-section rather than the circular profile of standard cables. This unique geometry provides specific advantages in applications involving frequent movement, tight spaces, and organized cable routing.

Flat cables are specifically engineered for dynamic applications where cables must flex, bend, or travel repeatedly, featuring conductors arranged in a single plane to minimize twisting forces and maximize flexibility while maintaining compact dimensions. These cables are essential in material handling, crane systems, automated storage, and industrial automation where space constraints and continuous motion are primary concerns.

Common Flat Cable Applications

Festoon Systems
Festoon systems² use trolleys that travel along I-beams or C-tracks to deliver power and control signals to moving equipment:

• Overhead cranes and gantry cranes
• Automated storage and retrieval systems (AS/RS)
• Conveyor systems with moving components
• Monorail systems in manufacturing facilities

The flat cable profile allows multiple cables to nest together efficiently on festoon trolleys, reducing the overall system width and minimizing cable sway during travel.

Pendant Control Systems
Pendant Control Systems are used when pendant cables hang vertically from hoists, cranes, or robotic systems:

• Crane pendant controls
• Hoist operator stations
• Robotic arm connections
• Adjustable workstation power drops

Flat cables resist twisting better than round cables, preventing the spiral tangling that commonly occurs with suspended round cables.

Traveling Equipment
Any equipment that moves along a fixed path benefits from flat cable design:

• Bridge cranes and jib cranes
• Automated guided vehicles (AGV) charging stations
• Linear motion systems
• Transfer cars and shuttle systems

Flat Cable Construction Characteristics

Understanding flat cable construction helps explain why specialized cable glands are necessary:

Feature	Flat Cable Design	Impact on Cable Gland Selection
Cross-section	Rectangular or oval	Requires wide-entry cable gland design
Conductor arrangement	Side-by-side in single plane	Even pressure distribution critical
Flexibility	High flexibility in one axis	Strain relief must accommodate bending direction
Width-to-height ratio	Typically 3:1 to 6:1	Standard round seals won’t work
Jacket material	Often specialized compounds	Seal material compatibility essential

When Thomas contacted me from Hamburg, his festoon system used flat cables measuring 32mm wide × 8mm thick. He’d been trying to force these into M25 round cable glands (25mm diameter), which crushed the cable into an hourglass shape, damaged conductors, and created gaps that allowed water ingress. The solution required a completely different approach.

Why Do Standard Cable Glands Fail on Flat Cables?

The fundamental problem is simple: round cable glands are engineered for circular cables, and flat cables violate every assumption in their design. Using standard cable glands on flat cables doesn’t just compromise performance—it actively damages your cables and creates safety hazards.

Standard round cable glands fail on flat cables because their circular compression seals cannot conform to rectangular profiles, resulting in uneven pressure distribution that deforms the cable, damages internal conductors, compromises IP ratings through seal gaps, and provides inadequate strain relief for the cable’s primary flex axis. These failures lead to premature cable replacement, equipment downtime, and potential safety incidents.

Specific Failure Modes

Seal Compression Failure
Round seals compress uniformly around circular cables. When forced onto a flat cable:

• Excessive pressure concentrates on the narrow edges (top and bottom)
• Minimal pressure on the wide faces (sides)
• Gaps form along the wide faces, destroying IP rating
• Cable jacket deforms under edge pressure
• Internal conductors may be damaged by compression

I’ve seen cases where installers tightened round cable glands so aggressively trying to seal flat cables that they actually severed conductors inside the cable jacket. The result was intermittent electrical faults that were incredibly difficult to diagnose.

Strain Relief Inadequacy
Flat cables flex primarily in one direction—perpendicular to their wide face. Standard cable gland strain relief mechanisms:

• Don’t account for directional flexibility requirements
• May restrict movement in the intended flex direction
• Fail to prevent movement in the wrong direction (edge-wise bending)
• Create stress concentration points that accelerate cable fatigue

Installation Challenges
Forcing flat cables through round cable gland entries creates practical problems:

• Cable must be twisted or deformed to enter
• Difficult to maintain proper cable orientation
• Risk of conductor damage during installation
• Inconsistent results between installations
• Impossible to achieve proper torque specifications

Real-World Consequences

Last year, I worked with Fatima, an operations manager at an automotive parts warehouse in Dubai, UAE. Her facility used an automated storage system with festoon-powered retrieval cranes. They’d installed standard brass cable glands on their flat festoon cables, and within six months experienced:

• 40% of cable glands showing visible water ingress
• 12 complete cable failures requiring emergency replacement
• Average cable life reduced from expected 5 years to under 18 months
• Estimated cost impact: $45,000 in unplanned maintenance and downtime

After switching to proper flat cable glands from Bepto’s specialized product line, her facility has operated for over two years without a single cable-related failure. The investment in correct cable glands paid for itself within four months through eliminated downtime alone.

What Types of Cable Glands Work for Flat Cables?

Several cable gland designs can accommodate flat cables, each with specific advantages for different applications. Understanding these options helps you select the optimal solution for your festoon, pendant, or traveling cable system.

Flat cable glands fall into three primary categories: wide-entry compression designs with rectangular seal profiles, multi-piece adjustable clamp systems that conform to various cable dimensions, and split-body designs that allow cable installation without disconnection. Each type offers different benefits for sealing, strain relief, and installation convenience.

Wide-Entry Compression Cable Glands

These cable glands feature elongated entry holes and specially shaped seals designed for rectangular cable profiles.

Design characteristics:

• Oval or rectangular entry opening matching flat cable dimensions
• Custom-molded seals with flat internal profiles
• Compression mechanism that applies even pressure across cable width
• Available in nylon, brass, and stainless steel body materials

Advantages:

• Maintains IP65/IP67/IP68 ratings when properly installed
• Relatively simple installation procedure
• Good strain relief for moderate movement applications
• Cost-effective for standard flat cable sizes

Limitations:

• Requires precise cable dimension matching
• Limited adjustability for cable size variations
• May require custom seal profiles for unusual cable dimensions

Best applications:

• Fixed or slowly moving festoon systems
• Indoor pendant cables with moderate environmental protection needs
• Standard flat cable profiles with consistent dimensions

At Bepto, our wide-entry cable glands are available in sizes ranging from 10mm × 3mm up to 50mm × 15mm flat cable dimensions, covering most common festoon and pendant cable specifications.

Multi-Piece Adjustable Clamp Systems

These sophisticated cable glands use multiple components that can be adjusted to accommodate varying flat cable dimensions.

Design characteristics:

• Separate clamping plates or saddles that sandwich the flat cable
• Adjustable compression screws for precise pressure control
• Modular seal components that can be configured for different cable sizes
• Often include integral strain relief bridges or clamps

Advantages:

• Accommodates cable dimension variations (±2-3mm typical)
• Allows precise pressure adjustment to prevent cable damage
• Superior strain relief capabilities
• Can often handle slightly oval or irregular cable profiles
• Easier to achieve consistent, repeatable installations

Limitations:

• Higher cost than simple compression designs
• More complex installation procedure
• More components to inventory and maintain

Best applications:

• Heavy-duty crane festoon systems
• High-cycle applications (>100,000 flex cycles)
• Outdoor or harsh environment installations requiring IP68
• Applications where cable dimensions may vary between production batches

Split-Body Cable Glands

Split-body designs allow cable installation without disconnecting cable ends—critical for retrofit applications or when cables cannot be easily accessed.

Design characteristics:

• Cable gland body separates into two halves (typically hinged or bolted)
• Seals designed to close around cable when body halves join
• Locking mechanism to secure body halves together
• Available in both compression and clamp-style configurations

Advantages:

• Installation possible without cable disconnection
• Ideal for retrofit and maintenance applications
• Reduces installation time significantly
• Allows cable gland addition to existing installations

Limitations:

• Generally lower IP ratings than solid-body designs (IP54-IP65 typical)
• Higher cost due to complex construction
• More potential leak paths requiring careful installation
• May have reduced mechanical strength compared to solid-body designs

Best applications:

• Retrofit installations on existing festoon systems
• Maintenance situations where cable disconnection is impractical
• Temporary or semi-permanent installations
• Applications where IP54-IP65 protection is sufficient

Material Selection for Flat Cable Glands

Material choice depends on your environmental conditions and mechanical requirements:

Material	Advantages	Best For	Bepto Product Lines
Nylon (PA66)	Lightweight, corrosion-proof, cost-effective	Indoor festoon, light-duty pendant	Standard and UV-stabilized grades
Brass (Nickel-plated)	Good strength, moderate cost, excellent machinability	General industrial, moderate environments	CW617N with 5-10μm nickel plating
Stainless Steel 316	Maximum corrosion resistance, high strength	Outdoor, marine, chemical environments	Standard for harsh environment applications
Aluminum	Lightweight, good strength-to-weight ratio	Weight-sensitive crane applications	Available for specific applications

How Do You Select the Right Flat Cable Gland?

Selecting the correct flat cable gland requires careful consideration of cable dimensions, environmental conditions, movement characteristics, and installation requirements. A systematic selection process ensures optimal performance and longevity.

Flat cable gland selection requires measuring exact cable dimensions (width, thickness, and tolerance ranges), evaluating environmental protection requirements (IP rating, temperature, chemical exposure), assessing mechanical demands (flex cycles, strain forces, movement patterns), and considering installation constraints (access limitations, maintenance requirements, certification needs). Proper selection prevents the costly trial-and-error approach that many companies initially attempt.

Step-by-Step Selection Process

Step 1: Measure Cable Dimensions Accurately

Use digital calipers to measure:

• Cable width (W): Measure at multiple points along cable length
• Cable thickness (T): Measure at multiple points
• Dimensional variation: Note maximum and minimum dimensions
• Cable profile: Determine if truly rectangular, oval, or irregular

Important: Measure the actual installed cable, not just rely on manufacturer specifications. Cable dimensions can vary by ±5-10% from nominal specifications, especially after the cable has been in service.

Selection rule: Choose a cable gland with an entry range that encompasses your measured dimensions plus 10% tolerance. For example, a cable measuring 28-30mm wide × 7-8mm thick requires a cable gland rated for approximately 25-33mm × 6-9mm.

Step 2: Determine Required IP Rating

Consider your environmental exposure:

Environment	Minimum IP Rating	Recommended Cable Gland Type
Indoor, dry, clean	IP54	Nylon compression or split-body
Indoor, occasional moisture	IP65	Nylon or brass compression
Outdoor, rain exposure	IP67	Brass or stainless compression with quality seals
Washdown, submersion risk	IP68	Stainless steel multi-piece clamp system
Harsh chemical, marine	IP68	316 stainless steel with Viton seals

Step 3: Assess Mechanical Requirements

Evaluate the movement and stress characteristics:

Flex cycle estimation:

• Festoon systems: Calculate daily travel distance × cycles per day × days per year
• Pendant cables: Estimate lifting cycles per day × days per year
• Target: <50,000 cycles = standard design; >50,000 cycles = heavy-duty design

Strain relief requirements:

• Measure cable weight and suspended length for pendant applications
• Calculate pull forces for traveling festoon systems
• Identify primary flex direction (should align with cable’s thin dimension)

Step 4: Consider Installation Factors

Practical installation considerations often determine final selection:

Access limitations:

• Can cable ends be disconnected? If no → split-body design required
• Is cable gland accessible from both sides? If no → consider installation sequence carefully
• Will maintenance require cable gland removal? If yes → choose designs with easy disassembly

Certification requirements:

• UL/CSA³ required? → Verify cable gland has appropriate listings
• ATEX/IECEx for hazardous areas? → Select certified explosion-proof designs
• Marine certifications? → Specify marine-grade cable glands with appropriate approvals

Selection Example: Thomas’s Hamburg Crane Project

Remember Thomas from Hamburg with the crushed festoon cables? Here’s how we solved his selection challenge:

Cable specifications:

• Measured dimensions: 31-33mm wide × 7.5-8.5mm thick
• Application: Outdoor bridge crane festoon system
• Environment: IP67 required (outdoor, occasional rain)
• Flex cycles: ~80,000 per year (high-duty)
• Installation: New construction, cable ends accessible

Selection decision:
We specified Bepto’s brass multi-piece adjustable clamp cable glands:

• Size: 28-35mm × 6-10mm (accommodates dimensional variation)
• Material: Nickel-plated brass (adequate corrosion resistance, good value)
• Seal material: EPDM (weather-resistant, temperature range -40°C to +100°C)
• IP rating: IP68 (exceeds IP67 requirement, provides safety margin)
• Strain relief: Integral clamp bridge design for superior flex cycle performance

Results:

• Installation completed without cable damage
• IP68 rating verified through pressure testing
• 2+ years of operation with zero cable gland failures
• Estimated cable life now tracking to exceed 7 years (vs. 18 months with previous round cable glands)

What Are the Installation Best Practices for Flat Cable Glands?

Proper installation is critical for flat cable glands—even more so than with round cables, because the non-circular geometry creates more opportunities for installation errors. Following systematic installation procedures ensures optimal performance and longevity.

Flat cable gland installation best practices include maintaining correct cable orientation throughout installation, applying even compression pressure across the cable width, verifying seal contact across the entire cable perimeter, implementing proper strain relief aligned with the cable’s flex direction, and documenting installation parameters for future maintenance reference. These practices prevent the common installation errors that compromise performance even with correctly selected cable glands.

Pre-Installation Preparation

Cable Preparation:

1. Clean cable surface thoroughly with isopropyl alcohol in the seal area
2. Remove any printing or markings in the seal zone (ink prevents proper sealing)
3. Inspect for damage to cable jacket, especially edge damage from handling
4. Mark cable orientation with tape or marker to maintain proper alignment during installation
5. Measure cable dimensions at the installation point to verify compatibility

Panel/Enclosure Preparation:

1. Verify hole dimensions match cable gland specifications (rectangular or oval as required)
2. Deburr holes carefully—sharp edges can damage flat cable edges during installation
3. Clean mounting surface to ensure gasket sealing
4. Check panel thickness is within cable gland specifications
5. Test-fit cable gland before threading cable through

Installation Procedure for Compression-Style Flat Cable Glands

Step 1: Component Assembly
Lay out all components in installation order:

• Locknut (if separate from body)
• Cable gland body
• Sealing washer/gasket (for panel seal)
• Flat cable seal(s)
• Strain relief components (if separate)
• Compression nut or clamp

Step 2: Thread Cable Through Components

• Maintain cable orientation (wide face horizontal, narrow face vertical—or as designed)
• Thread cable through components in correct sequence
• Avoid twisting or bending cable during threading
• Ensure cable extends sufficiently beyond final seal position

Step 3: Install Cable Gland in Panel

• Insert cable gland body through panel hole
• Verify gasket is properly positioned
• Hand-tighten locknut on interior side
• Check cable gland body alignment (should be square to panel)

Step 4: Position Seals and Strain Relief

• Slide seal components to correct position on cable
• Verify seal is centered on cable (equal overhang on all sides)
• Position strain relief components according to manufacturer specifications
• Ensure cable maintains correct orientation

Step 5: Apply Compression
This is the critical step where most installation errors occur:

For compression nut designs:

• Thread compression nut onto cable gland body
• Tighten gradually in multiple passes (don’t tighten fully in one pass)
• Monitor seal compression visually—should compress evenly across entire width
• Stop when seal just begins to extrude slightly (1-2mm) beyond compression nut
• Do not over-tighten—this is the most common error with flat cables

For clamp designs:

• Position clamp plates evenly on both sides of cable
• Insert and hand-tighten all screws first
• Tighten screws in cross-pattern (like wheel lug nuts) to ensure even pressure
• Use torque specifications if provided (typically 2-4 Nm for M4 screws, 4-6 Nm for M5 screws)

Step 6: Final Locknut Tightening

• Tighten panel locknut to specified torque
• Typical values: 10-15 Nm for M20 size, 15-20 Nm for M25 size, 20-25 Nm for M32 size
• Use calibrated torque wrench for critical installations

Step 7: Verification

• Visual inspection: Seal should show even compression around entire cable perimeter
• Pull test: Apply moderate hand force (approximately 50N) to verify strain relief
• Orientation check: Verify cable flex direction aligns with cable gland design
• Documentation: Record installation date, cable gland model, torque values applied

Special Considerations for Festoon Systems

Festoon installations have unique requirements:

Cable Support:

• Install cable support within 300mm of cable gland entry point
• Use festoon trolley designs that prevent edge-wise cable bending
• Ensure cable gland orientation allows natural cable drape without twisting

Movement Clearance:

• Verify cable gland body has adequate clearance during full travel range
• Check for potential impact points with trolley components or I-beam
• Allow for cable sway during rapid acceleration/deceleration

Multiple Cable Installations:
When installing multiple flat cables in close proximity:

• Maintain consistent cable gland orientation across all cables
• Space cable glands to prevent cable-to-cable contact during movement
• Use cable separators or guides if cables run parallel for extended distances

Common Installation Mistakes to Avoid

Mistake	Consequence	Prevention
Over-tightening compression	Cable damage, conductor breakage	Use torque specifications, monitor seal extrusion
Incorrect cable orientation	Poor strain relief, premature failure	Mark cable orientation before installation
Skipping seal cleaning	Reduced IP rating, leaks	Always clean with isopropyl alcohol
Uneven clamp pressure	Seal gaps, cable deformation	Tighten in cross-pattern, use torque wrench
Inadequate strain relief	Cable pull-out, flex fatigue	Follow manufacturer’s strain relief guidelines
Wrong seal material	Chemical attack, premature aging	Verify seal compatibility with environment

At Bepto, we provide detailed installation instructions specific to each flat cable gland model, including dimensional drawings, torque specifications, and troubleshooting guides. Our technical support team is available to assist with installation challenges—we’ve helped hundreds of customers achieve successful installations on their first attempt. 😊

Conclusion

Flat cables in festoon, pendant, and traveling applications require specialized cable glands designed specifically for their unique rectangular or oval profiles. Standard round cable glands will damage flat cables, compromise environmental protection, and lead to premature failures that cost far more than the investment in proper cable glands. By understanding flat cable characteristics, selecting cable glands with appropriate wide-entry designs and adjustable clamping mechanisms, and following systematic installation procedures that ensure even pressure distribution and proper strain relief alignment, you can achieve reliable performance and 5-10 year cable life in demanding dynamic applications. Whether you’re designing a new overhead crane system, retrofitting an existing festoon installation, or troubleshooting repeated cable failures, the principles outlined in this guide will help you select and install the right cable gland solution. At Bepto, we manufacture a complete range of flat cable glands with the quality certifications, technical documentation, and responsive support you need for successful installations—because we understand that specialized applications require specialized solutions.

FAQs About Cable Glands for Flat Cables

1. Understand the engineering principles of cable strain relief and why it’s critical for cable longevity. ↩

2. See a detailed explanation of how festoon systems work to manage cables on moving equipment. ↩

3. Find out what UL and CSA certifications mean for electrical component safety in North America. ↩
